AIR INLET:3/4" FNPT
LIQUID INLET :38 mm (1-1/2")
LIQUID DISCHARGE :38 mm (1-1/2")
CONNECTION TYPE :BSPT
MAX SUCTION LIFT CAPABILITY : 5.2m（Dry）
MAX FLOW RATE :380 lpm (126.8 gpm)
MAX PRESSURE :8.3 bar (120 psi)
MAX DIAMETER SOLIDS :6.5 mm (1/4'')
DISPLACEMENT PER STROKE :1.25L (0.32 gal)
