AIR INLET :3/4" FNPT
LIQUID INLET :51 mm (2")
LIQUID DISCHARGE :51 mm (2")
CONNECTION TYPE :BSPT
MAX SUCTION LIFT CAPABILITY :6.2m（Dry）
MAX FLOW RATE :680 lpm (179.6 gpm)
MAX PRESSURE :8.3 bar (120 psi)
MAX DIAMETER SOLIDS :6.5 mm (1/4'')
DISPLACEMENT PER STROKE :2.65 L (0.7 gal)
